Description
LOCTITE Retaining Compound 609 is a press fit/ general purpose, low viscosity, rapid-curing anaerobic adhesive that augments the strength of press fit assemblies up to 0.005″ (.127 mm) in diameter. Adds up to 3,000 PSI holding power. The green, high strength, anaerobic-curing retaining compound cures in the absence of air between close fitting metal surfaces, providing a high strength and corrosion-free bond.
Dimensions
Gap Fill Size – Retaining Compounds |
0.006 in |
Container Size |
1.7 fl oz |
Container Size – Adhesives |
1.69 oz |
Maximum Gap Fill Size |
0.15 mm |
Size |
50ml |
Gap Fill Size |
0.006 in |
Filling Gap Size |
Up to 0.006″ |
Details
Item |
Retaining Compound |
Shear Strength (PSI) |
2,300 psi |
Optimal Usage Temperature |
-65 Degrees to 300 Degrees F |
Color |
Green |
Compatible Materials |
Steel |
Container Type – Adhesives |
Bottle |
Application |
For Close Fitting Cylindrical Parts,Retaining |
Operating Temperature Range |
-65.0 °F – 300.0 °F |
Shear Strength |
2,290 psi |
Max. Temp. (F) |
300 Degrees F |
Compound Type |
Fast Cure, General Purpose Low Viscosity |
Standards |
29 CFR 1910.1200 |
Primer |
T |
Full Cure |
24 hr |
Type |
General Purpose |
Series |
609 |
Characteristics |
Fluorescent,Shear Strength High Shear Strength,Viscosity Low Viscosity |
Physical Form |
Liquid |
Compatible Primer Series |
Excel 612 |
Retaining Compound Properties |
For Close-Fitting Parts |
Minimum Viscosity |
120 cps |
Specific Gravity |
1.1 |
Primer Required |
Yes |
Color Family |
Green |
Clean Up Method |
Solvent, Wire Brush |
Maximum Viscosity |
120 cps |
Minimum Operating Temperature |
-65 Degrees F |
Full Cure Time |
1 day |
Cure Type |
Anaerobic |
Retaining Compounds Properties |
For Close Fitting Parts |
VOC Content |
40.46 g/L |
For Material Type |
Steel |
Product Form |
Liquid |
Working Time |
10 min |
Container Type |
Bottle |
Maximum Operating Temperature |
300 Degrees F |
Retaining Compound Strength |
High |
Flash Point |
200 Degrees F |
Brand & Series |
LOCTITE 609 |
Non-Toxic |
No |
Working Time Range |
6 to 10 min |
Storage Requirements |
8 Degrees to 21 Degrees C |
Chemical Base |
Methacrylate Ester |
Physical form |
Liquid |
Shear strength |
15.0 N/mm² |
Cure type |
Anaerobic Cure |
Specific gravity |
1.1 kg/m3 |
